MSR
Click picture for Zoom
Saler：Magnetic Components
Model：MSR0704-1205,MSRB0603-1005
Brief：
SMD shielded wire wound power inductors
Detail Descriptions
SMD Shielded Wire Wound Power Inductors (MSR Series)
|
Series |
Dimensions (mm) |
Inductance Range |
Rated Current |
Specification |
||
|
L |
W |
H |
||||
|
MSR0704 |
7.4 |
7.9 |
4.5 |
10µH - 270µH |
0.33~1.65 |
|
|
MSR1005 |
9.6 |
10.0 |
5.0 |
10µH - 470µH |
0.33~2.06 |
|
|
MSR1203 |
11.6 |
12.6 |
3.0 |
10µH - 470µH |
0.33~2.06 |
|
|
MSR1205 |
11.6 |
12.6 |
5.4 |
10µH - 820µH |
0.36~2.65 |
|
|
MSRB0603 |
5.6 |
6.2 |
3.2 |
10µH - 68µH |
0.42~1.0 |
|
|
MSRB0704 |
7.0 |
7.8 |
4.5 |
10µH - 270µH |
0.33~1.6 |
|
|
MSRB1005 |
9.0 |
10.0 |
5.5 |
10µH - 470µH |
0.33~2.1 |
|
