Detail Descriptions
SMD Common Mode Choke Coils (MSTM50 Series). RoHS Compliance
| Series | Dimensions (mm) | Inductance Range | Rated Current | Specification |
| MSTM50 | 16.8x19.2x10.2 | 0.59mH - 1.47mH | 2.8A - 5.6A |
 |
| Part Number | Inductance [mH] | DCR [mΩ] | Rated Current [A] | Cross Pulse P/N |
| MSTM50-02 | 0.59 ±35% | 21 | 5.6 | P0353NL |
| MSTM50-03 | 1.32 ±35% | 60 | 3.3 | P0420NL |
| MSTM50-04 | 1.47 ±35% | 80 | 2.8 | P0351NL |
| MSTM50-05 | 0.77 ±35% | 40 | 4.7 | P0422NL |
| MSTM50-06 | 0.22 ±35% | 60 | 3.3 | P0421NL |
